CZCL A-500M-5 5V 80A 400W large Load LED Power Supply

0 out of 5

$26.00

CZCL A-500M-5 5V80A 400W Large Load LED Power Supply Features:
1.Large load capacity: 400w output power.
2.high reliability Quality, High standart quality elements parts are adopted, 100% full load high temperature aging tested.
3. Anti-dust, Anti-Moisture, Anti-Static
4. Protection: overload and short cirtuit protection
5. 2 Year Warranty

SKU: CZCL-A-500M-5 Categories: ,

Description

CZCL A-500M-5 5V80A 400W Large Load LED Power Supply Features:

1.Large load capacity: 400w output power.

2.high reliability Quality, High standart quality elements parts are adopted, 100% full load high temperature aging tested.

3. Anti-dust, Anti-Moisture, Anti-Static

4. Protection: overload and short cirtuit protection

5. 2 Year Warranty



 CZCL A-500M-5 5V80A 400W Large LED Display Power Supply Parameters:

input voltage:88-132VAC/176-264VAC,47-63Hz Protection:undervoltage,Overload,Short circuit
Output power:400W Max Working temperature:-30~+60℃
Power factor:0.80@230Vac Storage temperature:-40℃~+100℃,20~95%RH
Insulation voltage:I/P-O/P:3.0KVac Safety standards:GB4943,UL60950-1,EN60950-1
I/P-FG:1.5KVac;O/P-FG:0.5KVac,1min Dissipate heat:cold
EMC Standards:: GB9254,EN55022 Inrush current: 80A/230VAC
Leakage current:0.30mA@230Vac Size:205X114X50mm

Additional information

Weight 0.65 kg
