Onbon BX-5A4 WIFI LED control card

Description

Onbon BX-5A4 WIFI LED control card

The initiated one for WIFI wireless cluster controller on the field of LED display screen!
The latest project and product must lead the market once again.
BX-5A4&WIFI wireless cluster LED controller is perfectly clustered with BX-5A4 and BX-WIFI wireless communication module.With stable performance and convenient structure installation. Absolutely, it will promote and lead the field of LED display screen WIFI wireless network techniques to get a speed development by it’s good performance,best quality and prices.

Features
Best techniques and quality;
Anti terrible environment; Support wide work temperature: -30℃～70℃；
Support firmware update online;

Advantages
1. Support 100M Ethernet, easy to install and use;
2. Fast speed of data transferring, which is stable and reliable;
3. Wide applied range:
(1) Laptop worked within 100M; Desktop could work by wireless router connecting with BX-5A4&WIFI wireless controller communication.
(2) All places covered  well by  wireless WIFI signal like: airports, high-speed-train stations, intelligent building and so on.

Technique parameters
Product name: BX-5A4&WIFI wireless controller
Recommend index: ★★★★★
Product status: Being brought to market in March 2012, always in stores;
Performance index: Controlling performance parameters are equal to BX-5A4;
Main functions: Data wireless transparent transmitting;
Support 100M Ethernet;
Support TCP/IP/UDP network
Support wireless router/bridge connection model network structure;
Support 802.11b/g/n wireless standard;
Support heartbeat signal, WIFI connecting indication;

Maximum power: ≤2.5W
Receiving sensitivity: (802.11b：-89dBm，802.11g:-81dBm，802.11n:-71dBm)
Maximum transferring distance : ≤200M  ( Suggesting the distance: ≤100M)
Wireless standard: 802.11 b/g/n
Work RF: 2.412GHz-2.484GHz
Antenna: 2.4GHz standard flake antenna
Work voltage: 5V (3.5V-6V)
Work temperature: -30℃～70℃

Application Specification
1. The latest product with high performance price; Compact structure, exquisite workmanship, simple and fast to installation;
2. Users should better adopt a proper waterproof protection when in the outdoor;
3. Pay more attention to the place for antenna, for the flake antenna of BX-5A4&WIFI controller is supposed to install to the outside of LED display screen
